Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
maserati ghibli (2016) rh cylinder head parts diagram

01.20.3 - RH cylinder head

Maserati Ghibli (2016) RH CYLINDER HEAD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 46328090
123 HEAD ASSEMBLY
Valid from engine: 38082 - 0. Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £1,539.32
from £1,539.32
This part replaces part number 673003151
TESTA COMPLETA 123 Genuine Maserati Part - New (to order)
# 001
MPN: 673000955
123 HEAD ASSEMBLY
Valid from engine: 0 - 38081. Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £1,539.32
from £1,539.32
TESTA COMPLETA 123 Genuine Maserati Part - New (to order)
# 002
MPN: 46328149
123 CYLINDER HEAD COVER ASSEMBLY
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £235.63
from £235.63
This part replaces part number 673001158
RH CAM COVER & GASKET Genuine Maserati Part - New (to order)
# 004
MPN: 673001234
HEAD GASKET KIT 123 0,96 WITH SCREW #NO HOLES#
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £174.10
from £174.10
KIT GUA.TEST.123 SP.0.96 CPL Genuine Maserati Part - New (to order)
# 004
MPN: 673001235
HEAD GASKET KIT 123 1,06 WITH SCREW #ONE HOLE#
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £174.10
from £174.10
Head Gasket Kit Genuine Maserati Part - New (to order)
# 004
MPN: 673001236
HEAD GASKET KIT 123 1,16 WITH SCREW #TWO HOLES#
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £174.10
from £174.10
KIT GUA.TEST.123 SP.1,16 CPL Genuine Maserati Part - New (to order)
# 005
MPN: 46328165
SEAL RING
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £14.02
from £14.02
This part replaces part number 673001294
ANELLO DI TENUTA Genuine Maserati Part - New (to order)
# 006
MPN: 673001154
NUT
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £1.11
from £1.11
DADO FLANGIATO Genuine Maserati Part - New (to order)
# 007
MPN: 46328762
BRACKET
Valid from assembly: 5039254. Suitable for cars with: EURO 6. Not for cars with: EURO 5. Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £102.18
from £102.18
STAFFA SUPP.Tubi GASOL. E DE Genuine Maserati Part - New (to order)
# 008
MPN: 46328350
BALL PIN
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £6.22
from £6.22
This part replaces part number 673001270
PERNO SFERICO Genuine Maserati Part - New (to order)
# 009
MPN: 46328341
123 BRACKET
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £18.40
from £18.40
This part replaces part number 673001248
STAF.SUPP.COPERCHIO ESTETICO Genuine Maserati Part - New (to order)
# 010
MPN: 673000964
CAPS AND PLUGS KIT
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £63.64
from £63.64
KIT TAPPI E SPINE TESTE Genuine Maserati Part - New (to order)
# 010
MPN: 673001233
engine gasket kit
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £471.57
from £471.57
GASKET KIT Genuine Maserati Part - New (to order)
# 011
MPN: 46328760
REAR BRACKET
Valid from assembly: 5039254. Suitable for cars with: EURO 6. Not for cars with: EURO 5. Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £102.18
from £102.18
STAFFA SUPPORTO RIPARO CALOR Genuine Maserati Part - New (to order)
# 012
MPN: 46328010
SCREW
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £1.11
from £1.11
This part replaces part number 673001000
SCREW Genuine Maserati Part - New (to order)
# 013
MPN: 46328016
STUD
Suitable for: AUTOMATIC | 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP | AUSTRALIA, CHILE, EUROPE, ITALY, JAPAN (RH DRIVE), UK, USA
from £1.11
from £1.11
This part replaces part number 673001024
STUD Genuine Maserati Part - New (to order)
