lamborghini revuelto coupe (2024) automatic gearbox parts diagram

300.01.00 - AUTOMATIC GEARBOX

Lamborghini Revuelto Coupe (2024) AUTOMATIC GEARBOX Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 001
                      MPN: 0DX300050
                      8-SPEED DUAL CLUTCH GEARBOX
                      from £43,587.45
                      from £43,587.45
                      TRANSMISSION Genuine Lamborghini - New (to order)
                      # 002
                      -
                      TRANSMISSION CARRIER
                      # 003
                      MPN: 47A907102E
                      BRACKET
                      from £107.65
                      from £107.65
                      BRACKET Genuine Lamborghini - New (to order)
                      # 004
                      MPN: 0DX901152
                      electric motor
                      NOT AVAILABLE SEPARATELY
                      from £25,182.71
                      from £25,182.71
                      electric motor Genuine Lamborghini - New (to order)
                      # 005
                      -
                      HI. VOLT. WIRE, TRACT. MOTOR
                      # 006
                      -
                      (GEARBOX OIL COOLER > OIL COOLER)
                      # 007
                      MPN: 0B9525049
                      VENT HOSE
                      from £35.89
                      from £35.89
                      SFIATO, DIFF.POST. Genuine Lamborghini - New (to order)
                      # 008
                      MPN: 47B321397
                      BRACKET
                      from £43.76
                      from £43.76
                      BRACKET Genuine Lamborghini - New (to order)
                      # 009
                      MPN: 47B321396
                      BRACKET
                      from £46.61
                      from £46.61
                      BRACKET Genuine Lamborghini - New (to order)
                      # 010
                      MPN: 47B301473
                      breather line
                      from £111.10
                      from £111.10
                      VENT TUBE Genuine Lamborghini - New (to order)
                      # 011
                      MPN: N10198301
                      EAR CRIMP HOSE CLAMP
                      13.3X7X0.6
                      from £1.71
                      from £1.71
                      EAR HOSE CLAMP 13.3X7X0.6 Genuine Lamborghini - New In stock
                      Ear Hose Clamp (N 10198301) Genuine Porsche Part - New (to order)
                      # 012
                      MPN: N10687201
                      SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (KOMBI)
                      M10X45
                      from £1.64
                      from £1.64
                      12-POINT SOCKET M10X45 Genuine Lamborghini - New In stock
                      bolt, with polygon socket hd. (N 10687201) Genuine Porsche Part - New (to order)
                      # 013
                      MPN: 47B899531
                      BUSH
                      BUSH Genuine Lamborghini - New (to order)
                      # 014
                      MPN: N10660901
                      SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
                      M10X40
                      from £4.28
                      from £4.28
                      TRIPLE SQUARE BOLT M10X40 Genuine Lamborghini - New In stock
                      bolt, with polygon socket hd. (N 10660901) Genuine Porsche Part - New (to order)
                      # 015
                      MPN: N10710402
                      OVAL HEXAGON SOCKET HEAD BOLT
                      M8X22
                      from £1.70
                      from £1.70
                      HEXALOBULAR SOCKET Genuine Lamborghini - New (to order)
                      # 016
                      MPN: WHT011511
                      O-RING
                      from £265.44
                      from £265.44
                      O-RING Genuine Lamborghini - New (to order)
                      # 017
                      MPN: 3W0971838
                      CABLE TIES
                      4,6X193MM 6,5/0,3-3,0MM
                      from £0.78
                      from £0.78
                      CABLE TIE BASE 6.50X200 Genuine Lamborghini - New (to order)
                      # 018
                      MPN: N10196103
                      OVAL SOCKET HEAD BOLT WITH HEX DRIVE
                      M6X18
                      from £0.78
                      from £0.78
                      HEXALOBULAR SOCKET M6X18 Genuine Lamborghini - New In stock
                      oval socket head bolt (N 10196103) Genuine Porsche Part - New In stock
                      # 019
                      MPN: N10659801
                      CABLE TIE WITH TERMINAL SOCKET
                      4,6X200MM
                      from £0.93
                      from £0.93
                      CABLE TIE BASE L-C4.6X193 Genuine Lamborghini - New In stock
                      KABELBINDERSOCKEL E3.5/4.6X193 (N 10659801) Genuine Porsche Part - New (to order)
                      # 020
                      MPN: 3D0971838F
                      CABLE TIE WITH HOLDER FOR WELD PIN:
                      5
                      from £1.85
                      from £1.85
                      CABLE TIE BASE Genuine Lamborghini - New In stock
                      # 021
                      MPN: 3D0971838N
                      CABLE TIES WITH BRACKET
                      from £0.72
                      from £0.72
                      CABLE TIE BASE 6.50X193.00 Genuine Lamborghini - New In stock
                      # 022
                      MPN: G052529A2
                      DUAL CLUTCH TRANSMISSION FLUID
                      1.0 LTR.
                      from £24.69
                      from £24.69
                      OIL Genuine Lamborghini - New (to order)
                      Dual clutch gearbox oil (G 052529A2) Genuine Porsche Part - New (to order)
                      # 023
                      MPN: 47B010541
                      NOTICE
                      SUPPLY VIN
                      from £17.99
                      from £17.99
                      STICKER TARGHETTE ANTITHEF Genuine Lamborghini - New (to order)
                      # 024
                      MPN: 02D525118B
                      ELBOW FITTING
                      from £8.78
                      from £8.78
                      ANGLED PIPE Genuine Lamborghini - New (to order)
