aston martin rapide (2010) mp3/usb media subsystem parts diagram

150108-30 - MP3/USB Media Subsystem

Aston Martin Rapide (2010) MP3/USB Media Subsystem Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 1
        MPN: 4G43-37-10950
        MODULE, AUXILIARY USB UNIT
        AUU
        from £431.10
        from £431.10
        AUU MODULE Genuine Aston Martin - New (to order)
        # 2
        MPN: 704169
        SCREW, M5 X10
        from £253.76
        from £253.76
        SCREW, M5 X10 Genuine Aston Martin - New (to order)
        # 3
        MPN: 8G43-19C166-AB
        USER INTERFACE PANEL
        Up To 15MY, with USB and iPod input. UIP
        from £53.40
        from £53.40
        AUU UIP Genuine Aston Martin - New (to order)
        # 3
        MPN: CD33-19C166-AE
        USER INTERFACE PANEL
        15MY, single USB. UIP
        from £101.85
        from £101.85
        USER INTERFACE PANEL Genuine Aston Martin - New (to order)
        # -
        MPN: HD33-19C166-AB
        TWIN USB UIP
        16MY on
        from £340.78
        from £340.78
        DUAL USB UIP Genuine Aston Martin - New (to order)
        # 4
        MPN: 4G43-37-10923
        AUXILIARY AUDIO 3.5MM INPUT
        from £4.34
        from £4.34
        AUX INPUT SOCKET-3.5 Genuine Aston Martin - New (to order)
        # 5
        MPN: 8G43-14D454-BB
        CABLE, UIP TO IPOD
        Up to 15MY
        from £166.10
        from £166.10
        CABLE, UIP TO IPOD Genuine Aston Martin - New (to order)
        # 6
        MPN: GG33-19H370-AA
        USB STICK
        from £82.58
        from £82.58
        USB STICK Genuine Aston Martin - New (to order)
